Electrostatic Studies of Fluoroalkanes F14H20

MDT-file: Download

AFM images of fluoroalkanes F14H20 adsorbate on Si substrate. The color contrast covers the topography variations in the 0-7 nm range, surface potential variations in the 0-1.1 V range and dC/dZ amplitude in the 0-0.15 V range.

Images are obtained with SPM NTEGRA Prima.

Image courtesy S. Magonov, NT-MDT Development, Tempe, AZ, US.


sp_300
sp_300
Fluoroalkanes F14H20
Kelvin-probe force microscopy image obtained in single-pass mode.

size: 1x1 um
SPM principle: Kelvin Probe Force Microscopy
phase.300
Fluoroalkanes F14H20


size: 1x1 um
SPM principle: Phase Imaging mode
d2c300
Fluoroalkanes F14H20
d2C/dZ2 image obtained in single-pass mode.

size: 1x1 um
SPM principle: Scanning Capacitance Force Microscopy
height.300
Fluoroalkanes F14H20


size: 1x1 um
SPM principle: Intermittent contact mode
