Ricin

MDT-file: Download

The AFM image of ricin (plant ribosome-inactivating protein type II). The image was obtained using a super sharp DLC probe, allowing details of the ricin substructure to be discerned. Molecules are deposited on the mica in different orientations; some well oriented molecules clearly show the A-subunit domain (fat arrows) and the two B-subunit domains (fine arrows).

The sample was kindly given by A.G. Tonevitsky and I. I. Agapov, Institute for transplantation and artificial organs, Moscow, Russia.


ricin500
ricin500
Ricin

The AFM image of ricin (plant ribosome-inactivating protein type II). The image was obtained using a super sharp DLC probe, allowing details of the ricin substructure to be discerned. Molecules are deposited on the mica in different orientations; some well oriented molecules clearly show the A-subunit domain (fat arrows) and the two B-subunit domains (fine arrows).

The sample was kindly given by A.G. Tonevitsky and I. I. Agapov, Institute for transplantation and artificial organs, Moscow, Russia.


size: 170x170 nm
SPM principle: Intermittent contact mode
