SThM imaging of graphene layers on Si

Topography and thermal conductivity mapping of graphene layes on Si.
Device: NTEGRA Prima
Tip: SThM
Image Courtesy: Arseny Kalinin

sthm_logo
sthm_logo
SThM imaging of graphene layers on Si

size: 25×25 μm
topography
Height

size: 25×25 μm
sthm
SThM current

size: 25×25 μm
sthm_section
SThM current profile
