1-pass PM SKM. Graphite on Gold

Surface potential measurements of peeled HOPG settled on golden coated Si.
Device: NTEGRA Spectra
Tip: NSG01\Pt
Sample Courtesy: Sergey Zayats
Image Courtesy: Sergey Zayats

ca_graphite_topo_kpfm_3d_2
ca_graphite_topo_kpfm_3d_2
1-pass PM SKM. Graphite on Gold

size: 15x15 um
SPM principle: Kelvin Probe Force Microscopy
_topo
Topography

size: 15x15 um
SPM principle: Kelvin Probe Force Microscopy
_surfpot
Surface potential

size: 15x15 um
SPM principle: Kelvin Probe Force Microscopy
over
Overlay of Surface potential Image onto the Topography Image

size: 15x15 um
SPM principle: Kelvin Probe Force Microscopy
